Specifications
| station number | 10 workstations |
| Max. Capacity of stirring | 5L |
| Stirring speed | 100~1100rpm |
| Temperature range | Plate Temperature: Ambient~ 200 ℃, Sample Temperature: Ambient~ 120 ℃ |
| Heating power | 600W |
| Input Power | 14W |
| Mixer size | Φ12*35mm |
| Pan size | 240*540mm |
| Panel Material | microcrystalline ceramics |
| Dimensions | 260*560*80mm |
| Power | 220V/110V |
| Machine Weight | 6.7kg |
| Ambient Temperature | 5~40℃ |
| Allowable Relative Humidity | <90% |
| Rated Frequency | 50/60Hz |
| Max. Capacity of stirring | 500mL |
| Mixer size | ≤40mm |
| output power | 4W |
Packing list
host x1, stirrer x1, Sensors x2, power cable x1, bracket x1 set, instruction manual x1, warranty card x1.
After-sales instructions
Warranty days: 365 days
If the product quality is not caused by human causes, the manufacturer provides 1 year free warranty service
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/21700/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
