Specifications
| Measurement principle | magnetic induction |
| Measuring range | 0 ~ 1250µm |
| margin of error | ±3% |
| resolution | 0.1µm |
| Minimum measurement surface | F7mm |
| Minimum radius of curvature | Convex 1.5mm, Concave 9mm |
| thinnest matrix | 0.5mm |
| probe | Fe |
| Measurement mode | Continuous measurement (CONTINUE) and single measurement (SINGLE) |
| Statistical function | Mean value (MEAN), MAX Maximum (MAX), MIN Minimum (MIN), number of tests (NO.), standard deviation (S. DEV); |
| data storage | 1560 measurements |
| Power | 2*1.5V |
| Display screen | black and white |
| Operating Temperature | 0~40℃ |
| Relative Humidity | 20~90%RH |
| Total Weight | 200g |
| Complete-built unit size | 163*78*33mm |
Packing list
host, standard test piece, substrate, 4 AA batteries, documents, instrument case
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
