Specifications
| Measurement angle | 20°/60°/85° |
| Measurement range | 0~2000GU(20°)；0~1000GU(60°)；0~160GU(85°) |
| Repeatability | 0-100GU：0.2GU；100-2000GU：0.2%GU |
| Error of indication | 0.1GU |
| Measuring Areas | 10*10mm(20°)；9*15mm(60°)；5*38mm(85°) |
| Measurement mode | Simple mode, master standard and sample measurement mode |
| Interface | USB, Bluetooth (optional) |
| Data storage | Can store 100 master standards, 10,000 samples |
| Operating language | Simplified Chinese, English |
| Dimensions | 165*51*77mm |
| Weight | Approx. 400g |
| Operating Time | 3000mAh lithium battery |
| Operating temperature | 0-40℃ |
| Relative Humidity | < 85%, no condensation |
| Measurement time | 0.5s |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/21850/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
