Specifications
| Number of strokes | 6 stitches |
| Scribing needle specification | Φ2mm；R 1mm |
| Travel | 300mm |
| Drying time range | 1 minute - 200 hours |
| execution standard | ASTM D5895, ISO 9117-4 and DIN EN 14022 |
| Motor power | Universal 24 V DC Power Adapter, 40W |
| dimensions | 335*400*190mm |
| operating temperature | -20 ° C - 70 ° C/-4 ° F - 158 ° F (non-condensing) |
| time accuracy | < 1% of the set time |
| Glass bed | 2 x three rails 305 mm x 100 mm x 3 mm (available), or 6 x independent rails 305 mm x 25 mm x 3 mm narrow Glass bed or custom bed, maximum dimensions W 200 mm, H 8 mm, L 400 mm |
| block | 9.5 kilograms/20.94 pounds |
| material | Anodic oxidation Aluminum, Glass, Nylon, Powder coated steel, Stainless steel |
| show | 128 x 64 pixel graphic LCD, 70 mm x 40 mm, white lighting, heated |
| language | English |
| input method | Illuminated tactile navigation button with triple function |
