Specifications
| Pump maximum flow | 80L/min |
| head | 12m |
| Ultimate Vacuum | 0.098Mpa (under standard atmospheric pressure, circulating water temperature 0~25 ℃) |
| Single head pumping Volume | 10L/min |
| Number of air extraction heads | 5 |
| Storage tank Volume | 35L |
| Working Voltage | AC220V 50Hz |
| Motor power | 370W |
| Noise | Less than 50dB |
| Dimensions | 440*340*840mm |
| Weight | 32kg |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/22358/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
