GREELOY GA-S302 oil-free scroll Air Compressor

GA-S302

Oil-free scroll Air Compressor

Description

Power: 4.4KW

Speed: 2900 rpm

Discharge volume: 480L/min at 8Bar

Noise: 75dB

Start and stop pressure: 5-8Bar

Gas storage tank: 100L (optional)

Net weight: 220kg

Product size: 885*520*1220mm

Driving mode: motor direct connection

Air outlet diameter: G 1

The advantages of stable exhaust volume of SiLai scroll Air Compressor:

At present, the exhaust volume of most Air Compressors on the market is generally marked as rated flow, but the actual operating pressure of users is mostly 5-8bar. At this time, the actual flow rate is only 50-30% of the marked flow rate, which is often easy to cause problems for users when selecting models. Troubled. However, during the pressure change process of our oil-free scroll Air Compressor from 0 to 8, the exhaust volume is always stable, that is, the marked flow rate is always the flow rate at 8 kg.

Advantages and features of Silicon Lai oil-free scroll Air Compressor:

Ultra-long continuous operation - using the international professional oil-free scroll air compression technology, the unit has the advantages of high stability, ultra-energy saving, ultra-quiet, and high cost performance.

High reliability - it is the Air Compressor with the fewest components among currently known Air Compressors in the world. There is no metal contact except the bearings during operation. The air compression module and motor are integrated, so the vibration is small and the reliability is high.

Low noise - because there is no knocking sound of the valve plate and impact sound of the air flow, the suction and exhaust are continuous and stable, and the air flow pulsation is extremely small. The minimum noise of the whole machine is only 60dB, which is more in line with environmental protection requirements.

The failure rate is extremely low - the volumetric efficiency is high, the pressure difference between adjacent working chambers is small, so the leakage is very small; there is no suction and exhaust valve, so the resistance loss of the intake and exhaust is almost zero; the air compression module and the motor are integrated, so the transmission There is no loss; there is no metal contact except the bearings, no friction and wear of the moving mechanism, and high mechanical efficiency. This is the main reason why the scroll compressor saves much more energy than other Air Compressors.

Low maintenance costs - there are fewer main parts and less wearing parts, so it can be regarded as almost a maintenance-free Air Compressor. At the same time, there is no gearbox in the driving part, eliminating the need for oil consumption and frequent maintenance, saving money and worry.

100% oil-free - there is no oil or carbon pollution in the entire system that is in contact with the air, and the gas is clean.

Effective and low-cost - Our oil-free scroll Air Compressor uses a three-phase 380V AC motor, which has good starting performance and high motor efficiency.

Applicable fields: industrial manufacturing, experimental analysis, biotechnology, measuring instruments, water treatment, environmental monitoring, automation, scientific and technological communications, petrochemical industry, environmentally friendly energy, aerospace technology, automobile braking, printing and other equipment that require a clean air source.

Packing list：

[Note]Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
