Specifications
| Measurement range | 150~960HLD、10~69.5HRC、19~666HB、80~999HV、30~100HS |
| Error of indication | ±6HLD(HLD=760) |
| Indication Repeatability | 6HLD(HLD=760) |
| Optional Impact Device | D、G、C、DL、DC、D+15 |
| Hardness system | HL/HB/HRC/HRB/HRA/HV/HS |
| PC communication | Yes. |
| Display | True color LCD display and WOINDOWS interface |
| Print roll diameter | 30±0.5mm |
| Paper width | 56.5±0.5mm |
| Power Supply | Integrated lithium battery |
| temperature | 0-40° |
| Dimensions | 238*90*38mm |
| Weight | 440g |
| Measurement direction | 360° |
Packing list
host X1, manual X1, certificate X1, warranty card X1, instrument case X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/22733/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
