Specifications
| Measurement principle | Magnetic Induction or eddy Current |
| Measurement range | Probe decision |
| margin of error | One point calibrate: probe determined, standard probe +/- (3% H + 1), two point calibrate: probe determined, standard probe +/- [（ 1~ 3%) H + 1] |
| Resolution | 0.1μm |
| statistical function | Measurement times, MAX Maximum, MIN Minimum, Average, Standard deviation |
| Data storage | 1560 Measured values |
| Power Supply | 2*1.5V |
| Operating temperature | 0~40℃ |
| Relative Humidity | 20~90%RH |
| Minimum radius of curvature | Minimum radius of curvature: convex 1.5, concave 9mm Minimum area diameter: 0019 7mm Basic critical thickness: 0.5mm |
| Machine Weight | 200g |
| Machine size | 163*78*33 |
| Operating Mode | Direct mode (DIRECT) and group mode (Appl) |
| Measurement mode | Direct mode (DIRECT) and group mode (Appl) |
| Shell material | plastic shell |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/22735/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
