Specifications
| Measurement principle | Magnetic Induction or eddy Current |
| Measurement range | Probe decision |
| margin of error | One point calibrate: probe determined, standard probe +/- (3% H + 1), two point calibrate: probe determined, standard probe +/- [（ 1~ 3%) H + 1] |
| Resolution | 0.1μm |
| statistical function | Measurement times, MAX Maximum, MIN Minimum, Average, Standard deviation |
| Data storage | 1560 Measured values |
| Power Supply | lithium battery |
| Operating temperature | 0~40℃ |
| Relative Humidity | 20~90%RH |
| Minimum radius of curvature | Minimum radius of curvature: convex 1.5, concave 9mm Minimum area diameter: 0019 7mm Basic critical thickness: 0.5mm |
| Print function | Yes. |
| Machine Weight | 420g |
| Machine size | 238*90*38mm |
| Operating Mode | Direct mode (DIRECT) and group mode (Appl) |
| Measurement mode | Direct mode (DIRECT) and group mode (Appl) |
| Shell material | Mg aluminum alloy |
| Print roll diameter | 30±0.5mm |
| Paper width | 56.5±0.5mm |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
