Specifications
| DC Voltage | 99.99mV/999.9mV/9.999mV/99.99V/600V |
| DC Voltage - Accuracy | 0.5%+2 |
| AC Voltage | 99.99mV/999.9mV/9.999mV/99.99V/600V |
| AC Voltage - Accuracy | 1.2%+3/1.0%+10 |
| DC current | 999.9uA、9999uA、99.99mA、600mA、10A |
| DC current - Accuracy | 1.0%+2、2.0%+2、3.0%+2 |
| AC current | 999.9uA、9999uA、99.99mA、600mA、10A |
| AC current - Accuracy | 1.0%+5、2.0%+5、3.0%+5 |
| resistance | 999.9Ω/9.999kΩ/99.99kΩ/999.9kΩ/9.999MΩ/99.99MΩ |
| Resistance - Accuracy | 0.8%+2/3.0%+5 |
| capacitor | 9.999nF/99.99nF/999.9nF/9.999uF/99.99nF/999.9nF/9.999mF/99.99mF |
| Capacitance - Accuracy | 3.0%+10/3.5%+10 |
| frequency | 9.999Hz~9.999MHz/9.999Hz~9.999KHz |
| Frequency - Accuracy | 0.1%+5 |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/22814/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
