Specifications
| Coating method | Wire rod/drawdown blade |
| Coating size | 300*400mm |
| Application width | 300mm |
| Coating speed | 5~ 180Mm/s (< 5mm/s can be customized) |
| Spreader thickness range | 0~10mm |
| Vacuum pump configuration | external |
| Vacuum Area | 300 * 400Mm (can be customized) |
| Vacuum aperture | Φ1.2mm |
| Coating rod specification | Accuracy 0.001mm, effective application width 170mm (Spreader thickness is determined according to the bar model) |
| Applicator Specification | 400Mm long |
| Key control mode | Touch screen control |
| Regulator display Accuracy | ±0.001mm |
| Display | digital |
| Total power consumption | 60W |
| Host Power | 220V 50Hz |
| Dimensions | 690*410*520mm |
| Machine Weight | 65Kg |
| Optional | Leakage tank, substrate fixture, trimming horizontal height support foot device, Glass plate, Silicone pad and Weight (for applications with uneven substrate thickness of Spreader) |
| Customizable function | Jet system device, UV solid-containing device, automatic inking system |
Packing list
Film Applicator X1, External vacuum pump X1, doctor blade X1, wire rod X1, product manual X1
After-sales instructions
Warranty days: 365 days
