Specifications
| Rated Voltage | AC 220 V |
| Rated Frequency | 50/60Hz |
| Input Power | 2200W |
| output power | 1500W |
| drive type | Brushless DC Motor |
| Max Torque | 716.2N.cm |
| Max Torque | 2148.5N.cm |
| Operating Mode | S1 (continuous) min |
| Rotation speed display | LCD |
| Control mode | Touch screen control mode |
| Speed range | 50~2000rpm |
| Speed regulation mode | Promise |
| Timer | 1 ~ 6000min |
| Rotation speed dynamic detection function | Yes |
| Rotation speed trend Linear dispersion | Yes |
| Temperature dynamic detection function | Yes |
| Rotation speed memory function | Yes |
| Overload protection | Yes |
| Impeller fixing method | Quick chuck |
| Rotary collet clamping range | 3~16mm |
| Stirringrod penetration diameter | No |
| Impeller type | Dissolving Impeller (Material: SS 316L Stainless Steel) |
| Processing Capacity | 200L |
| maximum viscosity | 100000mPa.s |
| Environmental temperature | ≤40℃ |
| Allowable Relative Humidity | ≤80% |
| Protection level | IP 40；500mm ★ |
| Dimensions of the whole machine | 800*730*1250mm |
| Machine Weight | 52 kg |
| Impeller material | 3Cr13 stainless steel |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/22912/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
