Specifications
| Rated Voltage | AC100~240V |
| Rated Frequency | 50/60Hz |
| Input Power | 162W |
| output power | 110W |
| drive type | Brushless DC Motor |
| Max Torque | 13.1N.cm |
| Max Torque | 39.0N.cm |
| Operating Mode | S1 (continuous) |
| Rotation speed display | TFT |
| Speed range | 30~2000rpm |
| Speed regulation mode | stepless speed regulation |
| Timer | 1~6000min |
| Impeller fixing method | Collet |
| Rotary collet clamping range | Φ2~10mm |
| Stirringrod penetration diameter | Φ10mm |
| Impeller type | Three Blade Spiral Impeller |
| Processing Capacity | 20L |
| maximum viscosity | 100000mPa·s |
| Environmental temperature | ≤40℃ |
| Allowable Relative Humidity | ≤80% |
| Dimensions of the whole machine | 215*310*600mm |
| Machine Weight | 7.6kg |
| Protection level | IP40 |
