Specifications
| Rated Voltage | AC 220V |
| Rated Frequency | 50/60 Hz |
| Input Power | 510W |
| output power | 300W |
| Rated torque | 13.6 N.cm |
| Operating Mode | S1 (continuous) |
| Operation control mode | Combined control knob |
| Speed range | 2000~18000rpm |
| Speed regulation mode | stepless speed regulation |
| Rotation speed display | LED |
| Timer | 1~1000min |
| Approved torque | 13.5 N.cm |
| Work head material | SS 304 stainless steel |
| Adapt work head | 12G/28G |
| Ambient Temperature | ≤40℃ |
| Allowable Relative Humidity | ≤80% |
| Dimensions | 215*310*720mm |
| Machine Weight | 9.7kg |
| Processing Capacity | 30~800mL，90~7000mL |
| Max. Processing Viscosity | 1000cp，6000cp |
| Rotor maximum linear velocity | 11m/s；19m/s |
| Maximum immersion liquid height | 110mm；150mm |
| Work head specification | 12mm；28mm |
| Working head length | 170mm；230mm |
| Operating temperature(MAX) | 120℃ |
| Work head material | SS 304 |
| Bearing material | PTFE |
| Minimum immersion liquid height | 35mm；50mm |
Packing list
Mulser x1, 12G work head x1, 28G work head x1, manual x1, warranty card x1
After-sales instructions
Warranty days: 365 days
【After-sales service】
1. The whole machine is guaranteed nationwide, and the warranty is one year (except for vulnerable parts and man-made damage);
2. After-sales service is provided by the original factory;
3. Free maintenance during the warranty period, and long-term technical support outside the warranty period.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/22919/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
