Specifications
| Capacity | 60L |
| Speed range | 30~2200rpm |
| Speed display | LCD |
| Timer | 9999min |
| Stir time settings | Yes. |
| Speed display resolution | ±1rpm |
| Speed memory function | Yes |
| Speed regulation | Crude and fine tuning |
| Max Torque | 80N.cm |
| Maximum Viscosity | 60000mPa·s |
| Impeller fixing method | Self-locking chuck |
| Rotary collet clamping range | Ph0.5 ~ 10mm |
| safety protection | Collet protective cover, safety buckle, non-slip pad |
| safety protection | Display fault, stop automatically |
| safety protection | Display fault, stop automatically |
| Input power | 160W |
| output power | 150W |
| Rated Voltage | 100~240VAC |
| Rated frequency | 50/60Hz |
| power | 160W |
| Protection class | IP42 |
| Allowable environment temperature | 5~40℃ |
| Allowable environment humidity | ≤80% |
| Data Interface | RS232 |
| Dimensions | 186*83*220mm |
| Total Weight | 3kg |
Packing list
Complete-built unit (including bracket, four-leaf stirringrod and baseplate) X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
