Specifications
| Lighting method | Transmission: D/0 (diffuse illumination, 0 ° direction reception); approximate CIE15 specifies 0/0 (parallel light illumination/0 degree reception); meets standards: ASTM D1003/1044, CIE No.15, GB/T 3978, GB 2893, GB/T 18833, ASTM E308, DIN5033 Teil7 |
| Integrating sphere size | F154mm |
| lighting source | 360~780Nm combined LED light source |
| Spectroscopic method | Concave grating |
| sensor | 256-Pixel dual array CMOS image sensor |
| Measurement Wavelength range | 360~780nm |
| wavelength spacing | 10nm |
| Half Bandwidth | 10nm |
| Transmittance range | 0~200% |
| Measurement aperture | Transmission: Φ25.4mm |
| Color space | CIE LAB,XYZ,Yxy,LCh,CIE LUV,Musell,s-RGB,HunterLab,βxy,DIN Lab99 |
| Color difference formula | ΔE*ab,ΔE*uv,ΔE*94,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*00, DINΔE99,ΔE(Hunter) |
| Chromaticity indicator | Haze (ASTM D1003/1044), Transmittance T, WI (ASTM E313, CIE/ISO, AATCC, Hunter), YI (ASTM D1925, ASTM 313), TI (ASTM E313, CIE/ISO), Isochromatic Spectral Index Mt, lightfastmess, color fastness, force, coverage Cobalt Platinum Index, Gardner Index |
| Observer angle | 2°/10° |
| Observation light source | D65,A,C,D50,D55,D75,F1,F2,F3,F4，F5，F6,F7,F8,F9，F10,F11,F12 |
| show | Light spectrum graphs/data, sample chromatic values, color difference values/graphs, chromaticity graphs, Color simulation, Pass/Fail results, Color bias |
| Measurement time | About 1.5s |
| Sexual repeability | Spectral transmittance: test transmission reference white standard deviation within 0.05% (400~700nm: within 0.04%): chromatic value: Φ25.4mm, ΔE * ab within 0.03 (after instrument preheating correction, the average value of 30 times of transmission reference white is measured at intervals of 5s |
| Inter-station difference | Φ25.4mm, ΔE * ab within 0.15 (the measurement average value of 5 standard transmission color plates from the original factory) |
| Weight | Approx. 9.6kg |
| Power Supply | DC 24V, 3A power adapter Power |
| Lighting source life | 5 years more than 3 million measurements |
| Display | TFT true color 7inch, capacitive touch screen |
| interface | USB, print serial port |
| Store data | 5000 master standards and 20,000 samples |
| language | Simplified Chinese, Traditional Chinese, English |
| Operating temperature range | 0~40℃（32~104°F） |
| Storage temperature range | -20~50℃（-4~122°F） |
| Standard accessories | Power adapter, manual, quality management software (official website download), data cable, reflection whiteboard, reflection black cylinder, transmission blackboard, 25.4 caliber, transmission test fixture assembly |
| Optional accessories | Micro printer |
Packing list
host, power adapter, manual, quality management software (official website download), data cable, reflection whiteboard, reflection black cylinder, transmission blackboard, 25.4 caliber, transmission test fixture assembly
