Specifications
| Lighting method | 45/0 (45 annular uniform illumination 0 ° reception); conforms to standard CIE No.15, GB/T 3978, GB 2893, GB/T 18833, ISO7724-1, ASTM E1164, DIN5033 Teil7, GB 2893, GB/T 18833 |
| Integrating sphere size | Φ48mm |
| lighting source | Combination LED light source, UV light source |
| spectroscopy | Concave grating spectroscopy |
| Sensors | 256 pixel dual array CMOS image sensor |
| Wavelength range | 400~700nm |
| wavelength interval | 10nm |
| Light spectrum half bandwidth | 10nm |
| Reflectance Measurement Range | 0~200% |
| Measurement caliber | Dual diameter: MAV: φ 10mm; SAV: φ 5mm |
| Color space | CIE LAB,XYZ,Yxy,LCh,CIE LUV,HunterLAB,βxy |
| color difference formula | ΔE*ab,ΔE*uv,ΔE*94,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*00,ΔE（Hunter） |
| Viewing Angle | CIE 2°/10° |
| observation light source | D65,A,C,D50,D55,D75,F1,F2(CWF),F3,F4,F5,F6,F7(DLF),F8,F9,F10(TPL5),F11(TL84),F12(TL83/U30) |
| display mode | Light spectrum plots/data, sample chromatic values, color difference values/plots, pass/fail results, Color bias |
| Measurement time | About 1.5s |
| Spectroscopic reflectance repeability | MAV, standard deviation within 0.08% (400~700nm: within 0.18%) |
| stand-alone difference | ΔE*ab<0.15 |
| measurement mode | Single measurement, average measurement (2~ 99 times) |
| Dimensions | 184*77*105mm |
| Weight | Approx. 600g |
| battery life | Lithium battery, 5000 cycles in 8 hours |
| Lifetime of lighting source | More than 3 million measurements in 5 years |
| Display | TFT true color 3.5inch, capacitive touch screen |
| Data Interface | USB, Bluetooth ® 4.0 Dual Mode (2.1 Compatible) |
| data storage | 1000 master standards and 30,000 samples |
| operating language | Simplified Chinese, English |
| Operating environment | 0~40 ℃, 0~85% RH (no condensation), altitude: less than 2000m |
| Storage environment | -20~50 ℃, 0~85% RH (no condensation) |
| Light spot size | MAV:Φ8mm；SAV:Φ4mm |
| Chromatic value repeability | MAV, Delta E * ab within 0.03 |
Packing list
host, power adapter, data cable, built-in lithium battery, manual, quality control software (official website download), black and white correction box, protective cover
After-sales instructions
Warranty days: 1095 days
【Warranty Terms】
1. The manufacturer of this product promises a warranty period of 2 years.
2. Freight sharing limit during the warranty period: the sender pays.
3. Damage caused by improper use by customers is not covered by the warranty.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/23219/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
