Specifications
| Lighting method | 45/0 (45 annular uniform illumination 0 ° reception); conforms to standard ISO 5-4, CIE No. 15 |
| lighting source | Combination LED light source, UV light source |
| Spectroscopic method | Concave grating spectroscopy |
| Sensors | 256-Pixel dual array CMOS image sensor |
| Wavelength range | 400~700nm |
| wavelength spacing | 10nm |
| Light spectrum half bandwidth | 10nm |
| Measurement conditions | Compliant with ISO 13655 measurement conditions: M0 (CIE light source A) M1 (CIE light source D50) M2 (UV-excluded illumination) M3 (M2 + polarized filter) |
| Density standard | ISO Status T、 E、A、I |
| Density index | Density value, Density difference, Dot area, Dot enlargement, Overprint, Printing characteristics, Printing contrast, Tone error and grayness |
| Measurement caliber | Customized single diameter: Φ2mm, Φ4mm, Φ8mm optional |
| Color space | CIE LAB,XYZ,Yxy,LCh |
| Color difference formula | ΔE * ab, ΔE * 94, ΔE * 00 |
| Chromaticity indicator | without |
| Viewing Angle | CIE 2 ° / 10 ° |
| Observation light source | A,C,D50,D55,D65,D75,F2,F7,F11,F12 |
| Measurement time | About 1.5s |
| Density, repeability | Density value: within 0.01D |
| Inter-station difference | ΔE * from < 0.2 |
| Measurement mode | Single measurement, average measurement (2~ 99 times) |
| Dimensions | 184*77*105mm |
| Weight | Approx. 600g |
| Battery life | Lithium battery, 5000 times in 8 hours |
| Lighting source life | 5 years more than 3 million measurements |
| Display | TFT true color 3.5inch, capacitive touch screen |
| Data Interface | USB |
| Data storage | 10000 articles |
| Operating language | Simplified Chinese, English, Traditional Chinese |
| Operating conditions | 0~40 ℃, 0~85% RH (no condensation), altitude: less than 2000m |
| Storage environment | -20~50 ℃, 0~85% RH (no condensation) |
Packing list
host, power adapter, data cable, built-in lithium battery, manual, quality control software (download required), black and white correction box, protective cover, polarization filter box, positioning plate
After-sales instructions
Warranty days: 1095 days
【Warranty Terms】
1. The manufacturer of this product promises a warranty period of 2 years.
2. Freight sharing limit during the warranty period: the sender pays.
3. Damage caused by improper use by customers is not covered by the warranty.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/23223/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
