Specifications
| Measurement angle | 60° |
| Measuring Areas | 9*15mm(60°) |
| Measurement range | 0~1000GU |
| Graduation | 0.1GU |
| Measurement mode | Basic mode, statistical mode, continuous mode, quality control mode |
| Measurement time | 0.5s |
| Repeatability | 0~100GU:±0.2GU ; 100~1000GU:±0.2%GU |
| Accuracy | Meet JJG 696 level 1 glossmeter requirements |
| Automatic shutdown time | 30~120 seconds optional |
| Calibrate | Automatic inspection and calibration/Manual calibration |
| Operating language | Simplified Chinese, English, Traditional Chinese |
| Data storage | 35,000 items (15,000 items in basic mode and continuous mode, 10,000 items in quality management mode, and 10,000 items in statistical mode) |
| Display | 2.3 inch black and white display |
| Dimensions | 160*52*84mm |
| Weight | About 300g (including calibration box and battery) |
| Power | 1 AA alkaline battery (AA alkaline battery or NiMH rechargeable battery), can be measured more than 10,000 times; or use USB port |
| Interface | USB |
| software | GQC6 quality management software, Quality control report printing, more function expansion |
| Operating temperature | 0~40℃ |
| Storage temperature | -20~50℃ |
| Relative Humidity | < 85% RH, no condensation |
| Standards | ISO2813、GB/T9754、JJG696 |
Packing list
Gloss Meter, USB data cable, manual, GQC quality management software (download required), Calibration plate
After-sales instructions
Warranty days: 1095 days
【Warranty Terms】
1. The manufacturer of this product promises a warranty period of 2 years.
2. Freight sharing limit during the warranty period: the sender pays.
3. Damage caused by improper use by customers is not covered by the warranty.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/23226/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
