Specifications
| Rotor speed | 0.3/0.6/1.5/3/6/12/30/60rpm |
| Measurement range | 100~2000000mPa·s |
| Torque | 67.37 μN.m |
| Rotor specification | M1~M4 |
| number of rotors | 4 sticks |
| Measurement Accuracy | ±1%F.S |
| Repeatability | ±0.2%F.S |
| Display information | % / mPa·s / Pa·s / kPa·s（cP/P switching possible） |
| I/O Connector | Interface for TS-20 |
| input signal | Start/stop signal (no Voltage touchpoint) |
| Output signal | Measurement signal, measurement stop signal, buzzer signal (open collector electrode) |
| Automatic stop | Time, viscosity |
| warm up | Yes (* 60 minutes long) |
| Zero Setting | available |
| Range setting | available |
| Operating temperature | 0~40℃ |
| Allowable Relative Humidity | < 90% no condensation |
| Materials that invade the liquid part | stainless steel |
| Power | AC100~230V |
| power consumption | Less than 20W |
| Dimensions | 105*220*320mm |
| Base size | 290*300*430mm |
| Weight | About 6KG |
Packing list
Viscometer X1, certificate of conformity, warranty card, manual
After-sales instructions
Warranty days: 365 days
Where to buy Dongji Nissan viscometer products from the North and South Tide Mall,During the warranty periodFailure or damage caused by non-human factorsFree repairs.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/23334/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
