Specifications
| Thermocouple Temperature range | -35~950℃ |
| K-type Thermocouple Error | +/- 0.75 ℃ (-35~ + 75 ℃) +/- 1% Measured value (+ 75.1~ + 950 ℃) |
| Thermocouple resolution | 0.1℃ |
| Temperature Measurement Range | -35~950℃ |
| Accuracy | +/- 2.5 ℃ (-35~ -20.1 ℃) +/- 1.5 ℃ (-20~ + 19.9 ℃) +/- 0.75 ℃ (+ 20~ + 99.9 ℃) +/- 0.75% Measured value (+ 100~ + 950 ℃) |
| resolution | 0.1℃ |
| diameter | 155 x 58 x 195 mm |
| Operating temperature | -20~50℃ |
| shell | black/gray, metal screen |
| Optical inspection resolution | 75:1 16 mm @ 1200 mm (90%) |
| Optical inspection resolution | 1 mm @ 70 mm (90%) |
| Measurement ratio | T95:150ms scanning maximum/minimum/alarm limit: 100ms |
| Power Supply | 2AA battery |
| Battery life | 25 hours (without laser); 10 hours (laser aiming, backlight off); 5 hours (laser aiming, 50% backlight off) |
| Storage temperature | -40~70℃ |
| Weight | 465g |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
