Specifications
| power | 50-1800W continuously adjustable |
| Crushing Capacity | 1-1200ML (corresponding horn needs to be selected) |
| Display | True color capacitive touch screen display |
| Single ultrasound time | 0.1-99.9S |
| Single gap time | 0.1-99.9S |
| Total time (ultrasound + gap) | 1-99H59M59S |
| Frequency range | 19.5-20.5KHz |
| Temperature range | 0-100 ℃ (optional low temperature constant temperature) |
| Alarm function | Temperature, time, overload, no load, over temperature |
| Standard horn | F22mm |
| Optional horn | F3 、 6 、 10 、 15 、 20 、 25 、 28mm |
| duty cycle | 0.1-99.9% |
| Data storage | 20 groups |
| Power | 220V/110V/ 50Hz/60HZ |
| Dimensions | 410*225*290mm |
| Net Weight of ultrasonic host | 16kg |
| Ultrasonic host Gross Weight | 19kg |
| Packing size | 470*305*430mm |
| Sound box Gross Weight | 10kg |
| Sound box Packaging Dimensions | 350*350*550mm |
| Control method | MCU + TFT touch |
| Optional function | Computer communication + data printing + sound box lighting or sterilizing |
| Voice alarm and prompt function | Yes. |
Packing list
X1 set of ultrasonic generator, X1 set of vibration system (transducer assembly + 6MM), X1 set of sound insulation box (additional Encasement), X1 set of labjack (in the sound insulation box), X1 piece of power cord, X2 pieces of spare fuse (in the power cord bag), X1 copy of instruction manual, X1 copy of warranty card (including certificate of conformity), X1 piece of temperature probe (in the power cord bag)
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/23450/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
