Specifications
| power | 1000-3000W continuously adjustable |
| Crushing Capacity | 500~5000ml |
| Display | True color capacitive touch screen display |
| Single ultrasound time | 0.1-99.9S |
| Single gap time | 0.1-99.9S |
| Total time (ultrasound + gap) | 1-99H59M59S |
| Frequency range | 19.5-20.5KHz |
| Temperature range | 0-100 ℃ (optional low temperature constant temperature) |
| Alarm function | Temperature, time, overload, no load, over temperature |
| Standard horn | Φ40mm extended type |
| Optional horn | Φ20, 35, 38, 40 extended type, 50mm |
| duty cycle | 0.1-99.9% |
| Data storage | 20 groups |
| Power | 220V/110V/ 50Hz/60HZ |
| Packaging Dimensions | 510*225*290mm |
| Net Weight of ultrasonic host | 17kg |
| Ultrasonic host Gross Weight | 21kg |
| Packaging Dimensions | 470*305*430mm |
| Sound box Gross Weight | 15kg |
| Sound box Packaging Dimensions | 430*415*730mm |
| Control method | MCU + TFT touch |
| Optional function | Computer communication + data printing + sound box lighting or sterilizing |
| Voice alarm and prompt function | Yes. |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/23451/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
