Specifications
| Rated Voltage | AC 100~240V |
| Rated frequency | 50/60HZ |
| Input power | 130W |
| output power | 100W |
| Drive type | DC brushless motor |
| Max Torque | 24N.cm |
| Duty Cycle | S1 (continuous) |
| Operation control method | Capacitive touch keyboard |
| Speed range | 20~2000rpm |
| Speed regulation | stepless speed regulation |
| Timer | 1~6000min |
| Speed display | TFT |
| Speed dynamic detection function | Yes |
| Speed memory function | Yes |
| safety protection | Overload protection |
| Impeller fixing method | Collet |
| Rotary collet clamping range | 2~13mm |
| Impeller type | Three Blade Spiral Impeller |
| Capacity | 20L |
| Maximum Viscosity | 100000mpa.s |
| Allowable environment temperature | ≤40℃ |
| Allowable environment humidity | ≤80% |
| Complete-built unit form factor | 250*350*835mm |
| Total Weight | 10kg |
| Max Torque | 50.0N.cm |
| Speed dynamic detection function | Yes |
Packing list
Stir host X1, stirringrod X1, base X1, power box X1, column X1, product certificate X1, support fixing frame X1, instruction manual X1
After-sales instructions
Warranty days: 365 days
If the product quality is not caused by human beings, the manufacturer provides 1 year free warranty service, except for accessories.
