Specifications
| Rated Voltage | AC 100~240V |
| Rated frequency | 50/60HZ |
| Input power | 400W |
| output power | 320W |
| Drive type | DC brushless motor |
| Max Torque | 200N.cm |
| Operation control method | Control knob |
| Speed range | 30~2000rpm |
| Speed regulation | stepless speed regulation |
| Timer | 1~6000min |
| Speed display | TFT LCD |
| Speed dynamic detection function | Yes |
| Speed memory function | Yes |
| safety protection | Overload protection |
| Impeller fixing method | Collet |
| Rotary collet clamping range | F2 ~ 10mm |
| Impeller type | Four Blade Spiral Impeller |
| Capacity | 100L |
| Maximum Viscosity | 130000mpa.s |
| Allowable environment temperature | ≤40℃ |
| Allowable environment humidity | ≤80% |
| Complete-built unit form factor | 600*320*220mm |
| Total Weight | 15kg |
| Max Torque | 360N.cm |
| Temperature display function | Yes |
| Key lock function | Yes |
| External temperature sensing interface | PT1000 |
| Temperature Measurement range | ~50-400℃ |
| Temperature measurement Accuracy | 0.1K |
| Hollow shaft | 12mm |
Packing list
Stir host X1, stirringrod X1, base X1, power box X1, column X1, product certificate X1, support fixing frame X1, instruction manual X1
After-sales instructions
Warranty days: 365 days
If the product quality is not caused by human beings, the manufacturer provides 1 year free warranty service, except for accessories.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/23939/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
