Lanyu LYD500W-T LABOratory High Shear Dispersion Homogenizer 18G/50~1500ml
SE
Three-core processor intelligent control main board, 2.8-inch TFT true color touch screen, real-time Voltage, frequency, current and power display. With torque Linear dispersion diagram display, the experimental data is more accurate. There are overload and overcurrent protection, local self-test, timing, memory and other functions, the speed can be preset and can be suspended at any time, the speed digital display, easy to operate. The working head is detachable
LanYu LYD500W-T (set two) High Speed Dispersion HomogenizerSPEC
LanYu LYD500W-T (set two) High Speed Dispersion HomogenizerDetails
LanYu LYD500W-T (set two) High Speed Dispersion HomogenizerPacking list
SKU
NB023945
Rated Voltage
AC220V
Rated frequency
50/60HZ
Input power
850W
output power
500W
Drive type
DC brushless motor
Stir shaft output torque
18N cm
Duty Cycle
100%
Operation control method
Touch knob
Speed range
100~28000rpm
speed control
stepless speed regulation
Timer
1~1000min
Speed display
TFT-LCD
Overload protection
Yes
Max Torque
18N.cm
throughput
50~1500ml
Allowable environment temperature
≤40℃
Allowable Relative Humidity
≤80%
Dimensions
215*30*700mm
Total Weight
10kg
Real-time Voltage, current, frequency, power display
Yes
Overload protection
Yes
Work head material
SS316 (stainless steel)
Work head specification
18G
LYD500W-T (set two)
High Speed Dispersion Homogenizer
Three-core processor intelligent control main board, 2.8-inch TFT true color touch screen, real-time Voltage, frequency, current and power display. With torque Linear dispersion diagram display, the experimental data is more accurate. There are overload and overcurrent protection, local self-test, timing, memory and other functions, the speed can be preset and can be suspended at any time, the speed digital display, easy to operate. The working head is detachable
Introduction
Lanyu Technology LYM200W-T laboratory mixer has a triple-core processor intelligent control motherboard, a 2.8-inch TFT true-color touch screen, and real-time Voltage, frequency, current, and power display. With torque curve display, the experimental data is more accurate. It has overload and overcurrent protection, local self-test, timing, memory and other functions. The speed can be preset and paused at any time. The speed is digitally displayed and easy to operate. The working head is detachable, which is convenient for replacement, cleaning and sterilization. The fuselage is all injection molded from high-quality engineering plastics to ensure safety and reliability during use. No-load speed range: 1000-28000rpm
Packing list:Homogeneous host X1, column wrench X1, base X1, working head X1, column X2, brush (spare parts) X1, pillar X1, product certificate X1, support fixing frame X1, instruction manual X1
[Note]Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
FAQ
QCan't the liquid level exceed this groove?
A
It cannot be lower than this red line position.
The maximum liquid level cannot exceed two-thirds of the rod length
Can exceed this groove
QHomogeneous, the particle size of the microspheres is tens of microns, and the homogeneous microsphere material is OK?
