Specifications
| rated voltage | AC220V |
| Rated frequency | 50/60HZ |
| Input power | 850W |
| output power | 500W |
| Drive type | DC brushless motor |
| Stir shaft output torque | 18N cm |
| working system | 100% |
| Operation control method | Touch knob |
| Speed range | 100~28000rpm |
| speed control | stepless speed regulation |
| Timer | 1~1000min |
| Speed display | TFT-LCD |
| Overload protection | Yes |
| Max Torque | 18N.cm |
| throughput | 80~5000ml |
| Allowable environment temperature | ≤40℃ |
| Allowable relative humidity | ≤80% |
| Dimensions | 215*30*700mm |
| Total weight | 10kg |
| Real-time voltage, current, frequency, power display | Yes |
| Overload protection | Yes |
| Work head material | SS316 (stainless steel) |
| Work head specification | 24G |
Packing list
Homogeneous host X1, column wrench X1, base X1, working head X1, column X2, brush (spare parts) X1, pillar X1, product certificate X1, support fixing frame X1, instruction manual X1
After-sales instructions
Warranty days: 365 days
If the product quality is not caused by human beings, the manufacturer provides 1 year free warranty service, except for accessories.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/23946/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
