Specifications
| Rated Voltage | AC220V |
| Rated frequency | 50/60HZ |
| Input power | 850W |
| output power | 500W |
| Duty Cycle | S1 (continuous) |
| Operation control method | Touch knob |
| Speed range | 1000~14000rpm |
| Speed regulation | stepless speed regulation |
| Timer | 1~1000min |
| Speed display | TFT-LCD |
| Overload protection | Yes. |
| rated torque | 35N.cm |
| Standard throughput | 500~40000mL |
| Maximum Max. Viscosity | 8000mpa.s |
| Allowable environment temperature | ≤40℃ |
| Allowable Relative Humidity | ≤80% |
| Dimensions | 215*310*700mm |
| Total Weight | 9.2kg |
| rated torque | 35N.cm |
| Rotor maximum linear speed | 18m/s |
| Work head material | SS304 |
| Work head specification | F70mm |
| Minimum immersion liquid height | 50mm |
| Maximum immersion liquid height | 236mm |
| Stator standard configuration | 5mm² 20mm² 50mm² |
Packing list
Emulsification host X1, M5 wrench X1, base X1, stator 5mm2X1, column X2, stator 50 mm2X1, pillar X1, brush (spare parts) X1, support fixing frame X1, product certificate X1, column wrench X1, instruction manual X1
After-sales instructions
Warranty days: 365 days
If the product quality is not caused by human beings, the manufacturer provides 1 year free warranty service, except for accessories.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/23949/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
