Specifications
| Lighting method | D/8 (Scattering Light source, 8 degrees Viewing Angle) SCS Optical inspection engine (spectroscopic integration system), ETC (real-time calibrated technology), with SCI (including specular reflection component)/SCE (excluding specular reflection component) synchronous measurement function |
| Sensors | Dual Path Array Sensors |
| Measurement time | 0.5s |
| Measurement caliber | Φ11mm |
| Spectroscopic reflectance Repeatability | Standard deviation within 0.08% |
| Operating language | Chinese, English |
| Interface | USB |
| Viewing Angle | CIE 2°/10° |
| Available Light Sources | CLEDs (Full Band Equalized Led Light sources) |
| Color difference formula | delta E * ab, delta E * CH, delta E * uv, delta E * cmc (2:1), delta E * cmc (1:1), delta E * 94, delta E * 00, delta Eab (Hunter), 555, shade classification |
| data storage | 40,000 test data |
| Power supply Voltage | Charging, repeability, continuous measurement 20000 times, 7.4V/6000mAh |
| display mode | Light spectrum map/data, sample chromatic value, color difference value/map, pass/fail result, Color bias, Color simulation, Display measurement area, Historical data color simulation, Manual input standard sample, Generate test report |
| Operating environment | 0~45 ℃, Relative Humidity 80% or less (at 35 ℃), no water condensation |
| Storage environment | -25~ 55 ℃, Relative Humidity 80% or less (at 35 ℃), no water condensation |
| Dimensions | 350*300*200mm |
| Weight | About 4.5kg |
| Integrating sphere size | Φ40mm |
| Wavelength range | 400~700nm |
| wavelength interval | 10nm |
| Light spectrum Bandwidth | 5nm |
| Reflectance Measurement Range | 0~200% |
| Reflectance resolution | 0.0001 |
| Color Space | CIE-L * a * b, L * C * h, L * u * v, XYZ, Yxy, reflectance, Hunterlab, Munsell MI, CMYK |
| Lighting source life | 10 years 3 million times |
| Inter-instrument Agreement | ΔE*ab<0.2 |
| Display | 5-Inch full-color true color screen |
| Color scheme | can be matched |
| UV Light source | No UV Light source |
| Chroma indicator | WI, YI, TI, homochromatic index MI, colour fastness, discoloration fastness, ISO luminance, 8 Glossiness, A density, T density |
| Repeatability of chromatic value | Delta E * ab 0.015, MAX Maximum 0.03 |
Packing list
Host x1, AC power cord x1, manual x1, Color management software x1, driver software x1, manual electronic version x1, Color management tutorial x1, data cable x1, black and white correction cylinder x1, Electronic Formula Guide x1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/240/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
