Specifications
| eyepiece | Large field of view WF10X (0019 22mm) |
| Brightfield objective | Infinite distance flat-field color difference objective (without coverslip) PL 5X/0.12, L10X/0.25, L40X/0.60, L60X/0.70 |
| Eyepiece tube | Triple eyepiece, tilted 30 °, (built-in polarizer, switchable) |
| emitter illumination system | 12V/50W halogen lamp, luminance adjustable; emitter illuminator with field of view bar, aperture bar, polarizer, (yellow, blue, green) color filter and frosted Glass |
| Focusing system | Coarse fretting coaxial focusing, fretting grid value: 2μm, with locking and limit device |
| converter | Four holes (inward ball positioning) |
| stage | Double-decked mechanical mobile (size: 210mmX140mm, moving range: 75mmX50mm) |
| Transmissive Illumination Light source | Abbe condenser NA.1.25 can be lifted up and down; Blue filter and frosted Glass; collector, halogen lamp for lighting (built-in field of view light bar); 12V 30W halogen lamp, luminance adjustable |
| Metallographic analysis system | Metallographic automatic analysis system JX2015 version; 3 million pixel map camera; 0.5X adapter mirror; micrometer (Accuracy is 0.01mm) |
Packing list
1. Host x1, 2. Eyepiece observation head x1, 3.10X flat field eyepiece x2, 4.5X objective x1, 5.10X objective x1, 6.40X objective x1, 7.60X objective x1, 8.light box x1, 9. Power cord x1, 10. Metallographic analysis software system x1, 11. Camera device x1, 12.0.5X camera adaptation mirror x1, 13.0.01/1mm ruler x1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/24150/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
