Specifications
| Coating method | Wire Rod Coating |
| Coating size | 190*400mm |
| Application width | 190mm |
| Coating speed | 5~ 180Mm/s (< 5mm/s can be customized) |
| Spreader thickness range | According to different rod specifications |
| Vacuum pump configuration | external |
| Heating mode | Baseplate heating |
| Heating temperature range | RT+~100℃ |
| Key control mode | Touch screen control |
| Regulator display Accuracy | ±0.001mm |
| Display | digital |
| Total power consumption | 120W |
| Applicable standards | GB/T 9756-2018 |
| Host Power | 220V 50Hz |
| Dimensions | 690*350*420mm |
| Machine Weight | 72Kg |
| Optional | Leakage tank, substrate fixture, trimming horizontal height support foot device, Glass plate, Silicone pad and Weight (for applications with uneven substrate thickness of Spreader) |
| Customizable function | Jet system device, UV solid-containing device, automatic inking system |
Packing list
Film Applicator X1, Wire Bar X1, External Vacuum Pump X1, Product Manual X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/24240/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
