Specifications
| Transmitter Frequency | 512Hz |
| Transmitter Transmitter Power | 0~ open 30W, can be automatically adjusted |
| Transmitter output impedance matching | 5-500Ω, automatic matching |
| Transmitter launch distance | 0.03-5 Km, can be gradually moved to 5Km |
| Transmitter working Power Supply | 14.8V lithium battery |
| Operating temperature of transmitter | -20℃~+50℃ |
| Transmitter Weight | 3.0 Kg (with battery) |
| Dimension | 274×225×98mm |
| Pipe finder positioning Accuracy | Pipeline burial depth +/- 5%; |
| Pipe sounding Accuracy | Pipeline burial depth +/- 5%; |
| Sounding range of tube probe | ≤6m; |
| Pipe finder working Power Supply | 7.4V lithium battery; |
| Operating temperature of probe | -20℃ ~+50℃ |
| Pipe probe Weight | 0.6Kg (including battery) |
| Pipe probe Dimensions | 165×90×68mm |
| Leak detection Accuracy | ≥0.25mm2 |
| Detector working Power Supply | 7.4V lithium battery; |
| Operating temperature | -20℃ ~+50℃ |
| Detector Weight | 0.6Kg (including battery) |
| Sine wave transmitter | Signal strength dB value display + earphone + metal Connector to improve Reliability in field use |
| Frequency | 512Hz |
| Dynamic range | Dynamic range is 100 times that of the original 2818 |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/24634/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
