Specifications
| Transmitter Frequency | 128Hz、512Hz、1KHz |
| Transmitter Transmitter Power | 0~ open 30W, can be automatically adjusted |
| Transmitter output impedance matching | 5-500Ω, automatic matching |
| Transmitter launch distance | 0.03-5 Km, can be gradually moved to 5Km |
| Transmitter working Power Supply | 14.8V lithium battery |
| Operating temperature of transmitter | -20℃~+50℃ |
| Transmitter Weight | 3.0 Kg (with battery) |
| Transmitter Dimensions | 274×225×98mm |
| Pipe finder positioning Accuracy | ≤10cm;; |
| Pipe sounding Accuracy | Pipeline burial depth +/- 5% (without interference from adjacent pipelines); |
| Pipe probe current Accuracy | +/- 5% of the actual current (without interference from adjacent pipelines); |
| Sounding range of tube probe | ≤6m; |
| Pipe probe Depth Measurement mode | Direct reading depth; |
| Pipe finder menu settings | Chinese and English menus; |
| Pipe probe backlight | With backlight function; |
| Frequency of Pipe Finder | 128Hz, 512Hz, 1KHz, Power Mode, Radio Frequency |
| Pipe probe data storage function | You can browse the data of on-site testing. |
| Pipe probe external interface | With external signal interface |
| Pipe finder positioning mode | Valley method (left and right arrow positioning), peak method, wide peak method, peak arrow method (left and right arrow positioning) |
| Pipe finder working Power Supply | 7.4V lithium battery; |
| Operating temperature of probe | -20℃ ~+50℃ |
| Pipe probe Weight | 2.3Kg (including battery) |
| Pipe probe Dimensions | 595×136×238mm |
| Leak detection Accuracy | ≥0.25mm2 |
| Detector working Power Supply | 7.4V lithium battery; |
| Operating temperature | -20℃ ~+50℃ |
| Detector Weight | 0.6Kg (including battery) |
| Detector Dimensions | 165×90×68mm |
| Sine wave transmitter | Signal strength dB value display + earphone + metal Connector + direct reading measurement depth, and current, positioning left and right arrows |
| Frequency | 512Hz |
| Dynamic range | Dynamic range is 100 times that of congeneric products |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
