Specifications
| Measurement conditions | D/8 (Light source, 8 degrees Viewing Angle) SCI (including specular reflection component) |
| Integrating sphere size | Should 40mm, Avian-D full diffuse reflection surface coating |
| Lighting source | CLEDs (Full Band Equalized Led Light sources) |
| Sensors | Dual Path Array Sensors |
| Measurement distance | 0.5mm |
| Self-calibrating | Built-in black and white calibrated |
| Protection level | IP67 |
| Wavelength range | 400~700nm |
| wavelength interval | 10nm |
| Light spectrum Bandwidth | 5nm |
| Measurement range | 0-200% |
| Resolution | 0.01% |
| Measurement caliber | Φ10mm |
| Measurement light source | A,C,D50,D55,D65,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12,CWF,U30.DLF,NBF,TL83,TL84.U35 |
| display mode | Light spectrum chart/data, sample chromatic value, color difference value, pass/fail result, Color bias, display measurement area, historical data color simulation, manual input standard sample, generate test report |
| interval time | 1s |
| Measurement time | Less than 20ms |
| Measurement parameters | CIE-L * a * b, L * C * h, L * u * v, XYZ, Yxy, reflectance |
| Color difference formula | ΔE*ab,ΔE*CH,ΔE*uv,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*94,ΔE*00 |
| Other chroma metrics | WI(ASTM E313-00,ASTM E313-73,CIE/ISO, |
| Repeatability | Chromatic value: Delta E * ab standard deviation ≤ 0.03, MAX Maximum ≤ 0.05 |
| Inter-instrument Agreement | ΔE*ab<0.2 |
| Operating environment | 0 ℃ -45 ℃, Relative Humidity 80% or less (at 35 ℃), no condensation |
| Storage environment | -25 ℃ -55 ℃, Relative Humidity 80% or less (at 35 ℃), no condensation |
| Interface | Industrial USB with customizable Miscellaneous interface |
| Power supply Voltage | +12DCV |
| Weight | 1.3kg |
| Dimensions | 100*112*120mm |
| Measurement parameter 2 | AATCC, Hunter, Taube Berger Stensby), YI (ASTM D1925, ASTM E313-00, ASTM E313-73), Tint (ASTM E313, CIE, Ganz), Isochromatic Index Milm, viscosity colour fastness, discoloration fastness |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/24765/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
