Specifications
| Lighting method | 45° |
| Measurement angle | Color Angle: 15 °, 45 °, 110 °; Particle Angle: Integrating Sphere Diffusion |
| Measurement parameters | Color parameters: L * a * b *, dE * ab; particle parameters: particle grade (G) |
| Wavelength range | 400~700nm |
| Light spectrum interval | 10nm |
| Measurement range | 0~500% |
| Resolution | 0.01% |
| Lighting source | LED |
| Measurement time | Less than 6s |
| Repeatability of chromatic value | dE≤0.05 |
| Inter-instrument Agreement | dE≤0.5 |
| Measurement area | Diameter 17mm |
| Viewing Angle | CIE 2°/10° |
| Lighting source | A、C、D50、D65、F2、F7、F11 & F12 |
| Interface | USB |
| Dimensions | About 145 * 58 * 99mm |
| Weight | Approx. 500g |
| Power supply Voltage | 3.7V/3000mAh rechargeable lithium battery |
| operating temperature | 0-40℃ |
| Storage environment | -20~50℃ |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 1095 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/24767/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
