Specifications
| Light source | CIE-A、CIE-C、CIE-D65 |
| follow the standard | ASTM D1003/D1044，ISO13468/ISO14782，JIS K 7105，JIS K 7361，JIS K 7136，GB/T 2410-08 |
| Measurement parameters | Haze (HAZE), Transmittance (T) |
| Light spectrum Response | CIE Light spectrum function Y/V (λ) |
| optical path structure | 0/d |
| Illumination and sample aperture size | 15mm/21mm |
| Measurement range | 0~100% |
| Haze resolution | 0.01 unit |
| Transmittance resolution | 0.01 unit |
| Haze Repeatability | Haze value < 10%, Repeatability ≤ 0.05%; Haze value ≥ 10%, Repeatability ≤ 0.1% |
| Repeatability | ≤ 0.1 unit |
| Thickness of the measured object | ≤150mm |
| store data | 20,000 values |
| interface | USB port |
| Power Supply | DC24V |
| Operating temperature | +10 – 40 ℃ (+50 – 104 °F) |
| Storage temperature | 0 – 50 ℃ (+32 – 122 °F) |
| Weight | 6kg |
| Optional accessories | Haze standard sheet, measurement fixture, custom diameter plate (5mm/7mm/10mm) |
Packing list
Whole machine x1
After-sales instructions
Warranty days: 1095 days
Non-artificially caused product quality problems, the manufacturer provides 1 year free warranty service
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/24768/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
