Specifications
| Flat field eyepiece | WF10X/Φ18 |
| Avoiding color difference objective | 4X/0.10, 10X/0.25, 40X/0.65 (spring), 100X/1.25 (oil, spring) |
| Total Magnification | 40X~1000X |
| observation head | Hinged 45 ° tilt, 360 ° swirl/spin |
| converter | Four holes (inward ball positioning) |
| Coarse fine-tuning focusing range | 30Mm fretting grid value: 2um coarse fretting coaxial focusing, coarse elastic adjustable, with locking and limit |
| stage | Simple single-layer Platform size 115X120mm Moving range 60X20mm Vernier grid value 0.1mm |
| Mechanical barrel length | 160mm |
| pupil distance | 55-75mm |
| condenser | 1.25NA Abbe condenser, variable light bar with color filter (up and down lift) |
| lighting system | 220V halogen lamp, tungsten halogen bulb 6V20W |
| Net Weight | 4.6 kilograms |
| Gross Weight | 3.8 kg |
| Instrument size | 22X36X36.5cm |
| Packaging Dimensions | 33.5X28X59cm |
Packing list
machine X1, operation manual X1, warranty card X1, certificate of conformity X1
After-sales instructions
Warranty days: 1095 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/25387/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
