Specifications
| Avoiding color difference objective | 45mm：4X，10X，40X（S），100X（S，Oil） |
| Flat field eyepiece | WF10X，WF16X |
| Total Magnification | 40X~1600X |
| observation head | Hinged binocular head, the pupil spacing can be adjusted by 55-75mm; 30 ° tilt, 360 ° can be turned |
| double-decked mechanical stage | Size 140X155mm, movement range in X-Y direction: 70X50mm |
| Variable light bar | φ 2-φ 30mm variable light bar with φ 32 color filter |
| condenser | N.A.1.25 Abbe condenser |
| Focusing range | Coarse fretting coaxial, focusing range 30mm, Accuracy 0.002mm |
| Light source | Built-in Light source: 6V/20W halogen lamp, 20W incandescent lamp, 1W LED lamp, rechargeable LED lamp; |
| Net Weight per unit | 6kg |
| Packaging Dimensions | Wooden box 1 table carton 38X34X50cm |
| Box Gross Weight | 11kg |
Packing list
machine X1, operation manual X1, warranty card X1, certificate of conformity X1
After-sales instructions
Warranty days: 1095 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/25393/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
