Specifications
| Large field eyepiece | WF10X/Φ18 |
| Avoiding color difference objective | X/0.10, 10X/0.25, 40X/0.65 (spring), 100X/1.25 (oil, spring) |
| Total Magnification | 40X~1000X |
| observation head | Translational 30 ° tilt, 360 ° swirl/spin |
| converter | Four holes (inward ball positioning) |
| Coarse fine-tuning focusing range | 30Mm fretting grid value: 2um coarse fretting coaxial focusing, coarse elastic adjustable, with locking and limit |
| double-decked mechanical stage | Size 140 * 140mm Moving range 75X45mm Vernier grid value 0.1mm |
| Mechanical barrel length | 160mm |
| pupil distance | 55-75mm |
| light source | 220V halogen lamp luminance adjustable, halogen tungsten bulb 6V20W (or 3W LED lamp) |
| Color filter | 1.25NA Abbe condenser, variable light bar with color filter (up and down lift) |
| Net Weight | 7 kg |
| Gross Weight | 8.5 kg |
| Instrument size | 21X36X48cm |
| Packaging Dimensions | 45X37X27cm |
Packing list
The whole machine X1, the operation manual X1, the warranty card X1, and the certificate of conformity X1.
After-sales instructions
Warranty days: 1095 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/25394/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
