Specifications
| Eyepiece tube | Binocular 30 ° tilt, binocular pupil distance adjustment range: 48~ 75mm. |
| Focusing system | Coarse micro-motion coaxial focusing, micro-motion grid value: 0.002mm, coarse elastic adjustable, with locking and limiting device, the effective stroke of the stage is 0~20mm. |
| converter | Four-hole internal positioning converter |
| stage | Double-layer mechanical mobile (size: 125mmX135mm, moving range: 35mmX75mm) |
| condenser | Abbe condenser, with variable aperture diaphragm and color filter holder, additional frosted lens, the condenser system can be lifted up and down. |
| Transmissive illumination source | High brightness white 3WLED lighting, adjustable brightness. |
| Host Power | AC 100~240V wide Voltage (suitable for LED lighting) |
| eyepiece | 10X flat field large field of view eyepiece, field of view diameter Φ20mm |
Packing list
completeness-built unit X1, operation manual X1, warranty card X1, certificate of conformity X1
After-sales instructions
Warranty days: 1095 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/25397/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
