Specifications
| Eyepiece tube | Three eyepieces, 30 ° tilt |
| Focusing system | Coaxial coaxial fretting focusing, with locking and limiting device, fretting grid value: 2 μm. |
| converter | Four holes (inward ball positioning) |
| stage | Double-decked mechanical moving stage, moving range: 30mm in longitudinal direction, 75mm in transverse direction. Culture dish pallet 1: inner groove size: 68mm; culture dish pallet 2: inner groove size: 34mm (width) X77.5mm (length), can be adapted to round culture dish < unk > 68.5mm |
| condenser | Plug-in phase contrast condenser working distance 30mm. |
| lighting system | 6V20W halogen lamp, adjustable luminance |
| Color filter | Frosted Glass, Blue and Green Color Filters |
Packing list
machine X1, operation manual X1, warranty card X1, certificate of conformity X1
After-sales instructions
Warranty days: 1095 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/25466/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
