Specifications
| converter | Five hole converter |
| Focusing system | Coarse fretting coaxial, fretting grid value: 2μ, coarse elastic adjustable, with locking and limit device, effective focusing stroke 11mm |
| condenser | Long working distance condenser, working distance 70mm, with plug-in phase contrast device |
| stage | Moving range (horizontal X vertical): 112mmX79mm, removable moving ruler |
| Culture dish pallet | Culture dish pallet: 86mm (width) X129.5mm (length), can be adapted to circular culture dish < unk > 87.5mm; 34mm (width) X77.5mm (length), can be adapted to circular culture dish < unk > 68.5mm; 57mm (width) X82mm (length) |
| phase contrast system | Phase contrast: pull plate type phase contrast condenser, adjustable center of phase contrast ring |
| lighting system | 9W LED, adjustable luminance |
| Color filter | Frosted Glass, Blue Color Filter |
| tuning tool | Hexagon wrench (M4, M5) |
| Total Magnification | 40X~400X |
| Mechanical barrel length | ∝ |
| Objective lens conjugate distance | ∝ |
| Flat field eyepiece | WF 10X; Field of view: < unk > 22mm; Eyepiece interface < unk > 30mm; Parfocal distance: 10mm |
| Eyepiece tube | 45 ° tilt, binocular pupil distance adjustment range: 48~ 75mm, eye point height from the table to 400mm. |
Packing list
machine X1, operation manual X1, warranty card X1, certificate of conformity X1
After-sales instructions
Warranty days: 1095 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/25476/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
