Specifications
| Eyepiece tube | Tilt 45 °, pupil distance adjustment range 53~ 75mm. |
| Focusing system | Coaxial coaxial fretting focusing, with locking and limiting device, fretting grid value: 2 μm. |
| converter | Five hole converter |
| stage | Fixed stage size: 227mmX208mm.; Glass round stage size: < unk > 118mm.; Mechanical moving size, moving range: horizontal (X) 114mm, vertical (Y) 77mm. |
| Culture dishes | Pallet 1: Inner groove size: 86mm (width) X129.5mm (length), can be adapted to circular culture dish < unk > 87.5mm; Pallet 2: Inner groove size: 34mm (width) X77.5mm (length), can be adapted to circular culture dish < unk > 68.5mm; Pallet 3: Inner groove size: 57mm (width) X82mm (length) |
| condenser | Long working distance condenser, working distance 55mm, with turntable phase contrast device |
| lighting system | 6V30W halogen lamp, adjustable luminance |
| Color filter | Frosted Glass, Blue and Green Color Filters |
| eyepiece | Large field of view WF10X (field of view number φ 22mm); centering telescope |
| objective lens | PLL 10X0.25、PLL 20X0.40、PLL 40X0.60 |
| Phase Contrast Objective | PLL 10X0.25 PHP2 working distance: 4.3 mm, coverslip thickness: 1.2mm. |
Packing list
machine X1, operation manual X1, warranty card X1, certificate of conformity X1
After-sales instructions
Warranty days: 1095 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/25477/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
