Specifications
| eyepiece | Large field of view WF10X (0019 18mm) |
| objective lens | Eliminate color difference 4X/0.10; Eliminate color difference 10X/0.25; Eliminate color difference 100X/1.25 (spring, oil); Fluorescent objective 20X/0.65 |
| Eyepiece tube | Three eyepieces (tilted 30 °) |
| Focusing system | Coaxial coaxial fretting focusing, with locking and limiting device, fretting grid value: 2 μm. |
| converter | Four holes (inward ball positioning) |
| stage | Double-decked mechanical mobile (size: 135mmX125mm, moving range: 75mmX35mm) |
| Abbe condenser | N.A.1.25 can be lifted up and down |
| Color filter | Blue filter |
| collector | For halogen lamps |
| Light source | 6V 20W halogen lamp, adjustable luminance |
| Dropper fluorescent device | Mercury lamp light box 100W/DC; power box: AC: 110V or 220V; fluorescent filter group B excitation optical band: 420~485nm; fluorescent filter group G excitation optical band: 460~550nm |
Packing list
machine X1, operation manual X1, warranty card X1, certificate of conformity X1
After-sales instructions
Warranty days: 1095 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/25478/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
