Specifications
| eyepiece | Large field of view WF10X (0019 22mm) |
| Infinity flat field objective | PL 4X/0.10; PL 10X/0.25; PLF L40X/0.85 (spring) (no magnification color difference); PL 100X/1.25 (spring, oil); |
| Eyepiece tube | Three eyepieces, 30 ° tilt |
| C interface | 1X C-type CCD dedicated interface |
| Light source of epifluorescence illumination | 3W high-brightness monochrome LED, which can be combined in monochrome or two colors |
| Fluorescent filter set B | Excitation optical band: 520~530nm |
| Fluorescent filter set G | Excitation optical band: 460~470nm |
| Fluorescent filter set UV | Excitation optical band 360nm~ 370nm |
| Fluorescent filter set V | Excitation optical band 390nm~ 400nm |
| Focusing system | Coarse fretting coaxial focusing, fretting grid value: 2μm, with locking and limit device |
| converter | Five holes (inward ball positioning) |
| stage | Double-decked mechanical mobile (size: 210mmX140mm, moving range: 75mmX50mm) |
| Transmissive Illumination Light source | Abbe condenser NA.1.25 can be lifted up and down; Blue filter and frosted Glass; collector adapted to LED lighting (built-in field of view light bar); 3W high-brightness white LED, luminance adjustable; |
Packing list
machine X1, operation manual X1, warranty card X1, certificate of conformity X1
After-sales instructions
Warranty days: 1095 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/25480/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
