Specifications
| eyepiece | Large field of view WF10X (0019 20mm) |
| objective lens | Infinity flat-field color difference objective PL 4X/0.10; Infinity flat-field color difference objective PL 10X/0.25; Infinity flat-field color difference objective PL 40X/0.65 (spring); Infinity flat-field color difference objective PL 100X/1.25 (spring, oil) |
| Eyepiece tube | Three eyepieces (tilted 30 °) |
| C interface | 1X C-type CCD dedicated interface |
| Focusing system | Coarse fretting coaxial focusing, coarse elastic adjustable, with locking and limiting device plate, fretting grid value: 2 μm. |
| converter | Four holes (inward ball positioning) |
| stage | Double-decked mechanical mobile (size: 210mmX140mm, moving range: 75mmX50mm) |
| Abbe condenser | N.A.1.25 can be lifted up and down |
| Color filter | Blue Color Filter; Frosted Glass |
| collector | For halogen lamps |
| Light source | 6V 20W halogen lamp, adjustable luminance |
| Dropper fluorescent device | Mercury lamp light box 100W/DC; power box: AC: 110V or 220V; fluorescent filter group B excitation optical band: 420~485nm; fluorescent filter group G excitation optical band: 460~550nm; fluorescent filter group UV excitation optical band 330~400nm; fluorescent filter group V excitation optical band 395~ 415nm |
Packing list
machine X1, operation manual X1, warranty card X1, certificate of conformity X1
After-sales instructions
Warranty days: 1095 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/25481/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
