Specifications
| eyepiece | Large field of view WF10X (field of view number φ 22mm); centering telescope |
| objective lens | PLL 10X0.25 working distance: 4.3 mm, coverslip thickness: 1.2mm; PLL 20X0.40 working distance: 8.0 mm, coverslip thickness: 1.2mm; PLL 40X0.60 working distance: 3.5 mm, coverslip thickness: 1.2mm. |
| Phase Contrast Objective | PLL 10X0.25 PHP2 working distance: 4.3 mm, coverslip thickness: 1.2mm; PLL 20X0.40 PHP2 working distance: 8.0 mm, coverslip thickness: 1.2mm; PLL 40X0.60 PHP2 working distance: 3.5 mm, coverslip thickness: 1.2mm. |
| Eyepiece tube | Tilt 45 °, pupil distance adjustment range 53~ 75mm. |
| Focusing system | Coaxial coaxial fretting, with locking and limiting device, fretting grid value: 2μm. |
| converter | Five hole converter |
| stage | 227mmX208mm |
| Stage Glass Round Stage Plate Dimensions | Ф118mm. |
| Stage mechanical moving size, moving range | Vertical 77mm, transverse 114mm, |
| Culture dish pallet one | Inner groove size: 86mm (width) X129.5mm (length), can be adapted to round culture dishes < unk > 87.5mm |
| Culture dish pallet two | Inner groove size: 34mm (width) X77.5mm (length), can be adapted to round culture dishes < unk > 68.5mm |
| Culture dish pallet three | Inner slot size: 57mm (width) X82mm (length) |
| Transmissive Illumination Light source | Turntable phase contrast condenser, working distance 55mm; 6V30W halogen lamp, adjustable luminance; Frosted Glass, Blue, Green color filter; |
Packing list
1. Instrument host x1; objective lens: 10X/20X/40X flat-field clear color difference objective each 10X/20X/40X phase objective each; eyepiece: 10X/22x1 pair, x1 for the center telescope; observation head: three eyes x1 (including a CCD interface); power cord x2; dust cover x1; fluorescent module V/UVx1 G/BGx1; fluorescent baffle x1; culture dish tray x1; fluorescent tube x2/latex stick one; fluorescent peripheral light box x1; inner hexagonal screw driver x1; installation instructions x1.
After-sales instructions
Warranty days: 1095 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/25484/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
