Specifications
| eyepiece | Large field of view WF10X (field number of viewing) |
| objective lens | Infinite working distance flat-field color difference objective |
| bright/dark field objective | PL L5X/0.12 BD working distance: 9.70 mm; PL L10X/0.25 BD working distance: 9.30 mm; PL L20X/0.40 BD working distance: 7.23mm; PL L50X/0.70 BD working distance: 2.50 mm; |
| Eyepiece tube | 45 ° tilt, pupil distance adjustment range 53~ 75mm. |
| CCD Connector | 1XCCD camera interface |
| Focusing system | Coaxial coaxial fretting focusing, with locking device, fretting grid value: 2μm. |
| converter | Five holes (inward ball positioning) |
| stage | Mechanical moving stage, Dimensions: 242mmX200mm, moving range 30mmX30mm. Circular rotatable stage size: the maximum outer diameter is 130mm, and the minimum light diameter is less than 12mm. |
| lighting system | 6V30W halogen lamp with adjustable luminance, suitable for XTL-18B; 12V50W halogen lamp with adjustable luminance, suitable for XTL-18BD; built-in field aperture, aperture aperture and pull plate polarizer; with frosted Glass, yellow, green and blue color filters |
Packing list
machine X1, operation manual X1, warranty card X1, certificate of conformity X1
After-sales instructions
Warranty days: 1095 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
