TEELEN TL-600A Monocular Polarizing Microscope

SE
Monocular simple polarization Microscope simple polarization with optical path compensator 40-1000 times
Model：
Certificate
Contact
Details SPEC Con

Teelen TL-600A Polarizing MicroscopeSPEC

Teelen TL-600A Polarizing MicroscopeDetails

Teelen TL-600A Polarizing MicroscopePacking list

SKU
NB025509
objective lens
45mm DIN消色差物镜4X，10X，40X（S），100X（S，Oil）；
Total Magnification
40X~1000X
stage
Diameter φ 120mm, 360 ° rotating load round table, scale value 1 °, vernier value 6 ′;
condenser
N.A.1.25 Abbe Condenser Lens; Should 2-Should 30mm Variable Light Bar with Should 32 Color Filter;
Focusing system
Coarse fretting coaxial, focusing range 14mm, fine-tuning Accuracy 0.01mm;
Detector
0 ° -90 ° rotating polarizer can be removed from the optical path;
compensator
Optical path compensator
polarizer
Polarization device located on the collector mirror, 360 ° rotatable; lambda test plate (top red), 1/4 lambda test plate
Light source
Built-in dimming 3.5V/1W high luminance LED light.
TL-600A
Polarizing Microscope
Monocular simple polarization Microscope simple polarization with optical path compensator 40-1000 times
TEELEN TL-600A Monocular Polarizing Microscope Picture

Instrument Introduction

TL600A monocular polarizing microscope can be used as a transmission polarizing microscope for routine testing and teaching, widely used in crystallography, analytical chemistry, medicine, biological science, environmental science, pharmaceuticals, toxicology and other fields; whether it is single polarized light, crossed polarized light or cone Optical observation, can provide clear, sharp images.

FAQ
QDoes the Polarizing Microscope Meet the Specifications of GB/T4074.10?
A Model TL-600A Polarizing Microscope Compliant
