Specifications
| observation head | Three head (53mm-75mm) |
| eyepiece | WF10X/18 (pair) |
| objective lens | 4X dry mirror, numerical aperture 0.10NA working distance 17.5mm; 10 × dry mirror numerical aperture 0.25NA working distance 6.6mm; 40 × spring dry mirror, numerical aperture 0.65NA working distance 0.64mm; 100 × spring oil mirror, numerical aperture 1.25NA working distance 0.19mm |
| Total Magnification | 40X~1000X |
| converter | Inward tilting four-hole objective lens converter |
| Mechanical barrel length | 160 mm |
| circular stage | Diameter φ 120mm, 360 ° rotating load circle table, scale value 1 °, vernier value 6 ′ |
| Focusing system | Coaxial coarse fine-tuning with focusing handwheel and parfocal lock, adjustment range: 25 mm Fine-tuning grid value: 0.002mm |
| Abbe condenser | N.A.1.25 Abbe Condenser Lens; Should 2-Should 30mm Variable Light Bar with Should 32 Color Filter |
| Polarizing device | Polarizer with swirling/spinning type and built-in polarizer for observation head |
| lighting system | Built-in dimming 6V20W halogen lamp |
| Power | 110-220V/50-60Hz |
Packing list
machine X1, operation manual X1, warranty card X1, certificate of conformity X1
After-sales instructions
Warranty days: 1095 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/25513/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
